Product Overview
SAME SKY CFM-8038BF-460-463 DC Axial Fan, 48 V, Square, 80 mm, 15 mm, Ball Bearing, 49.8 CFM
Product details
| Supply Voltage VDC |
48V |
| Fan Frame Size |
80mm |
| Bearing Type |
Ball Bearing |
| Noise Rating |
46.3dBA |
| Rated Speed |
6000rpm |
| Current Rating |
150mA |
| Air Flow - m3/min |
- |
| Product Range |
CFM-80BF Series |
| Fan Frame Type |
Square |
| External Depth |
15mm |
| Air Flow - CFM |
49.8CFM |
| Power Rating |
7.2W |
| Power Connection Type |
2 Lead Wires |
| IP Rating |
- |
| Static Pressure |
0.89Inch-H2O |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
SAME SKY |
| Part Number |
CFM-8038BF-460-463 |
| Quantity |
Each |
| Technical Data Sheet (3.79MB) EN |
View or download |
