Product Overview
ONSEMI NXH600N105L7F5P2HG IGBT Module, Three level Inverter, 429 A, 1.6 V, 1.08 kW, 175 °C, PIM
Product details
| IGBT Configuration |
Three level Inverter |
| Collector Emitter Saturation Voltage |
1.6V |
| Operating Temperature Max |
175°C |
| IGBT Termination |
Solder Pin |
| IGBT Technology |
IGBT 7 [Trench/Field Stop] |
| Product Range |
- |
| Continuous Collector Current |
429A |
| Power Dissipation |
1.08kW |
| Transistor Case Style |
PIM |
| Collector Emitter Voltage Max |
1.05kV |
| Transistor Mounting |
Panel |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
ONSEMI |
| Part Number |
NXH600N105L7F5P2HG |
| Quantity |
Each |
| Technical Data Sheet (1.92MB) EN |
View or download |
