Product Overview
Also known as
B43793G 657Q 11
Product details
| Capacitance |
650µF |
| Capacitance Tolerance |
-10%, +30% |
| Lifetime @ Temperature |
2500 hours @ 125°C |
| Capacitor Case / Package |
Radial Can |
| Product Diameter |
21mm |
| Product Width |
- |
| Product Range |
B43793 Series |
| Ripple Current |
6.7A |
| Operating Temperature Max |
140°C |
| SVHC |
No SVHC (25-Jun-2025) |
| Voltage(DC) |
125V |
| Capacitor Terminals |
Soldering Star |
| Polarity |
Polar |
| Lead Spacing |
- |
| Product Length |
- |
| Product Height |
49mm |
| ESR |
0.181ohm |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q200 |
Other details
| Brand |
TDK |
| Part Number |
B43793G0657Q011 |
| Quantity |
Each |
| Technical Data Sheet (137.00B) EN |
View or download |
