Product Overview
AD8475-EVALZ is an evaluation board for AD8475 precision, selectable gain, fully differential funnel amplifier. The AD8475-EVALZ board is designed for 8 lead MSOP so that a user can easily evaluate system performance when the AD8475 is mated with any Analog Devices, Inc., SAR ADC. The board can be installed with SMB connectors that mate directly to the Pulsar® Analog-to-Digital Converter Evaluation Kit. The board provides the user flexibility to configure the AD8475 in the desired gain (0.4 or 0.8) and to install suitable input and load impedances.
Product details
| Silicon Manufacturer |
Analog Devices |
| Kit Application Type |
Amplifier |
| Kit Contents |
Eval Board AD8475 |
| SVHC |
No SVHC (04-Feb-2026) |
| Silicon Core Number |
AD8475 |
| Application Sub Type |
Differential Amplifier |
| Product Range |
- |
Other details
| Brand |
ANALOG DEVICES |
| Part Number |
AD8475-EVALZ |
| Quantity |
Each |
| Technical Data Sheet (542.00KB) EN |
View or download |
