Product Overview
EVAL-AD7685-PMDZ is a 16bit, 250kSPS PulSAR® ADC PMOD evaluation board. The PMOD-compatible evaluation/prototyping board is a small form factor, low-cost analogue-to-digital conversion option. When prototyping, this board is used in conjunction with your favourite MCU or FPGA development board which has the SPI PMOD peripheral connector. Direct electrical and physical connection will enable you to quickly develop software for your system. This board can also be operated as an evaluation board using the System Demonstration Platform (EVAL-SDP-CB1Z) and an adaptor board (SDP-PMD-IB1Z). When operated with the System Demonstration Platform, a LabView software GUI is provided enabling the user to perform analysis of the ADC's performance.
- 16-Bit analogue to digital converters
- 250kSPS and unipolar, single-ended input
- Standard SPI PMOD header/pin out
- Connectable to 3rd Party FPGA and MCU platforms
Product details
| Silicon Manufacturer |
Analog Devices |
| No. of Bits |
16bit |
| Kit Application Type |
Data Converter |
| Kit Contents |
Eval Board AD7685 |
| SVHC |
No SVHC (04-Feb-2026) |
| Silicon Core Number |
AD7685 |
| Sampling Rate |
250kSPS |
| Application Sub Type |
ADC |
| Product Range |
- |
Other details
| Brand |
ANALOG DEVICES |
| Part Number |
EVAL-AD7685-PMDZ |
| Quantity |
Each |
