Product Overview
VISHAY MKP1848E54010JK2 Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 4 µF, ± 5%, DC Link, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
4µF |
| Typical Applications |
DC Link |
| Voltage(AC) |
- |
| Humidity Rating |
GRADE III (Test Condition A) |
| Lead Spacing |
27.5mm |
| Peak Current |
240A |
| ESR |
0.0095ohm |
| Product Length |
32mm |
| Product Height |
28mm |
| Output (kvar) |
- |
| Operating Temperature Min |
- |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
1kV |
| Capacitor Terminals |
PC Pin |
| dv/dt Rating |
60V/µs |
| RMS Current (Irms) |
9A |
| Product Diameter |
- |
| Product Width |
18mm |
| Ripple Current |
- |
| Product Range |
MKP1848E Series |
| Operating Temperature Max |
125°C |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
VISHAY |
| Part Number |
MKP1848E54010JK2 |
| Quantity |
Each |
| Technical Data Sheet (279.26KB) EN |
View or download |
