Product Overview
MT62F2G32D4DS-023 AUT:C is a mobile LPDDR5/LPDDR5X SDRAM. It has been developed according to ISO 26262:2018 requirements to provide a level of systematic fault coverage that allows its use in systems targeting up to ASIL D compliance.
- 17.1GB/s maximum bandwidth per channel, selectable CKR (WCK:CK = 2:1 or 4:1)
- Single x16 channel/die, double-data-rate command/address entry
- Differential data clocks (WCK-t/WCK-c), background ZQ calibration/command-based ZQ calibration
- Partial-array self refresh (PASR) and partial-array auto refresh (PAAR) with segment mask
- I/O type: low-swing single-ended, VSS terminated, VOH-compensated output drive
- Dynamic voltage frequency scaling core, single-ended CK, single-ended WCK and single-ended RDQS
- Operating voltage is 1.05V VDD2/0.5V VDDQ, automotive qualified
- 2 Gig x 32 configuration
- 315-ball TFBGA package
- Operating temperature range from -40°C to +125°C
Product details
| DRAM Type |
Mobile LPDDR5 |
| Memory Configuration |
2G x 32bit |
| IC Case / Package |
TFBGA |
| Supply Voltage Nom |
1.05V |
| Operating Temperature Min |
-40°C |
| Product Range |
- |
| Memory Density |
64Gbit |
| Clock Frequency Max |
4.266GHz |
| No. of Pins |
315Pins |
| IC Mounting |
Surface Mount |
| Operating Temperature Max |
125°C |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
MICRON |
| Part Number |
MT62F2G32D4DS-023 AUT:C |
| Quantity |
Each |
| Technical Data Sheet (133.00B) EN |
View or download |
