Product Overview
BOURNS 3299Y-1-503LF Trimmer, Multi Turn, Cermet, Top Adjust, 50 kohm, Through Hole, 25 Turns
Product details
| Trimmer Type |
Multi Turn |
| Adjustment Type |
Top Adjust |
| Potentiometer Mounting |
Through Hole |
| Product Range |
3299 Series |
| Resistance Tolerance |
± 10% |
| Trimmer Shape / Size |
3/8 Inch Square |
| Product Length |
9.53mm |
| Product Height |
10.3mm |
| Operating Temperature Max |
125°C |
| SVHC |
Lead (04-Feb-2026) |
| Element Material |
Cermet |
| Track Resistance |
50kohm |
| No. of Turns |
25Turns |
| Power Rating |
500mW |
| Temperature Coefficient |
± 100ppm/°C |
| Resistor Case / Package |
- |
| Product Width |
6.1mm |
| Operating Temperature Min |
-55°C |
| Qualification |
AEC-Q200 |
Other details
| Brand |
BOURNS |
| Part Number |
3299Y-1-503LF |
| Quantity |
Each |
| Technical Data Sheet (233.59KB) EN |
View or download |
