Product Overview
NXP MPF53BDAMMA1ES DC/DC CONV, BUCK, 12A/2.7V TO 5.5V/HWQFN
Product details
| Output Type |
Adjustable |
| Topology |
Buck (Step Down) |
| Input Voltage Max |
5.5V |
| IC Case / Package |
HWQFN |
| IC Mounting |
Surface Mount |
| Output Voltage Min |
500mV |
| Switching Frequency Typ |
2.2MHz |
| Operating Temperature Min |
-40°C |
| Product Range |
- |
| SVHC |
No SVHC (27-Jun-2018) |
| Automotive Qualification Standard |
AEC-Q100 |
| No. of Outputs |
1Outputs |
| Input Voltage Min |
2.7V |
| Max Output Current |
12A |
| No. of Pins |
24Pins |
| Output Voltage - Nom |
- |
| Output Voltage Max |
1.2V |
| Efficiency |
- |
| Operating Temperature Max |
125°C |
| Qualification |
AEC-Q100 |
| DC / DC Converter IC Case |
HWQFN |
| Switching Frequency |
3MHz |
Other details
| Brand |
NXP |
| Part Number |
MPF53BDAMMA1ES |
| Quantity |
Each |
