Product Overview
SAME SKY CFM-7010C-130-283-20 DC Axial Fan, 12 V, Square, 70 mm, 10.9 mm, omniCOOL, 18.11 CFM
Product details
| Supply Voltage VDC |
12V |
| Fan Frame Size |
70mm |
| Bearing Type |
omniCOOL |
| Noise Rating |
28.3dBA |
| Rated Speed |
3000rpm |
| Current Rating |
140mA |
| Air Flow - m3/min |
0.512m³/min |
| Product Range |
CFM-70C Series |
| Fan Frame Type |
Square |
| External Depth |
10.9mm |
| Air Flow - CFM |
18.11CFM |
| Power Rating |
1.32W |
| Power Connection Type |
3 Lead Wires, Tachometer |
| IP Rating |
- |
| Static Pressure |
0.06Inch-H2O |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
SAME SKY |
| Part Number |
CFM-7010C-130-283-20 |
| Quantity |
Each |
| Technical Data Sheet (1.58MB) EN |
View or download |
