Product Overview
PULSE ELECTRONICS HAA5-24D3H6 Isolated Through Hole DC/DC Converter, ITE, DIP, 5 W, 2 Output, 15 V
Product details
| Power Supply Applications |
ITE |
| Input Ratio |
- |
| No. of Outputs |
2 Output |
| Output Current - Output 1 |
200mA |
| Output Current - Output 2 |
-200mA |
| Isolation Voltage |
6kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
12.65mm |
| Input Voltage DC Min |
18V |
| Product Range |
HAAx Series |
| DC / DC Converter Type |
DIP |
| Output Power Max |
5W |
| Output Voltage - Output 1 |
15V |
| Output Voltage - Output 2 |
-15V |
| Output Regulation |
- |
| Input Voltage DC Nom |
24V |
| Width |
20.3mm |
| Depth |
31.7mm |
| Input Voltage DC Max |
36V |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
PULSE ELECTRONICS |
| Part Number |
HAA5-24D3H6 |
| Quantity |
Each |
