Product Overview
TDK B32714P7305J000 Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 3 µF, ± 5%, DC Link, Through Hole
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
3µF |
| Typical Applications |
DC Link |
| Voltage(AC) |
- |
| Humidity Rating |
GRADE II (Test Condition A) |
| Lead Spacing |
27.5mm |
| Peak Current |
- |
| ESR |
0.0161ohm |
| Product Length |
31.5mm |
| Product Height |
24.5mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-55°C |
| Qualification |
AEC-Q200 |
| Capacitor Case / Package |
Radial Box - 2 Pin |
| Capacitance Tolerance |
± 5% |
| Capacitor Mounting |
Through Hole |
| Voltage(DC) |
750V |
| Capacitor Terminals |
Radial Leaded |
| dv/dt Rating |
75V/µs |
| RMS Current (Irms) |
5A |
| Product Diameter |
- |
| Product Width |
15mm |
| Ripple Current |
- |
| Product Range |
B32714P Series |
| Operating Temperature Max |
125°C |
| SVHC |
No SVHC (25-Jun-2025) |
