Product Overview
RV8S-L-D48-D6 is a RV8 series 6mm solid state, slim interface relay. It provides a compact solution for general purpose relay requirements. It is ideal for PLC and electronic systems, industrial automation, panel builders, assembly machine applications and other applications that require high switching capability in compact space. The RV8 series interface relay can be used as interfaces between the controller and the actuator to switch small and medium size loads.
- Universal AC/DC socket with built-in surge suppression and green LED
- Lever for easy locking and removal of relay
- Operating temperature range from -20°C to +60°C
- UL/c-UL listed, IP20 degree of protection
- 1-pole, 1A (SPST) contact configuration
- Screw terminal
- 48V DC, 0.1A output voltage
- 6V DC input voltage
- 2,500V AC for 1 minute dielectric strength between contact and coil
Product details
| Contact Configuration |
SPST-NO |
| Operating Voltage Max |
48VDC |
| Relay Terminals |
Screw |
| Operating Voltage Min |
0VDC |
| Control Voltage Max |
12VDC |
| SVHC |
No SVHC (25-Jun-2025) |
| Load Current |
100mA |
| Relay Mounting |
DIN Rail |
| Switching Mode |
Non Zero Crossing |
| Control Voltage Min |
4.5VDC |
| Product Range |
RV8 Series |
Other details
| Brand |
IDEC |
| Part Number |
RV8S-L-D48-D6 |
| Quantity |
Each |
| Technical Data Sheet (1.48MB) EN |
View or download |
