Product Overview
SAME SKY CBM-9330B-240-507-20 Fan Blower, DC Brushless Motor, 24 V, DC, 93 mm, 29.5 mm, 21.7 CFM
Product details
| Blower Type |
DC Brushless Motor |
| Voltage Type |
DC |
| External Depth |
29.5mm |
| Air Flow - m3/min |
0.614m³/min |
| Bearing Type |
Ball Bearing |
| Power Rating |
7.2W |
| IP Rating |
- |
| Supply Voltage |
24V |
| Fan Frame Size |
93mm |
| Air Flow - CFM |
21.7CFM |
| Noise Rating |
47.5dBA |
| Power Connection Type |
2 Lead Wires, PWM Control, Tachometer |
| Product Range |
CBM-93B Series |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
SAME SKY |
| Part Number |
CBM-9330B-240-507-20 |
| Quantity |
Each |
| Technical Data Sheet (70.00B) EN |
View or download |
