Product Overview
SAME SKY CFM-A225B-120-350 DC Axial Fan, 12 V, Square, 120 mm, 25.4 mm, Ball Bearing, 69.74 CFM
Product details
| Supply Voltage VDC |
12V |
| Fan Frame Size |
120mm |
| Bearing Type |
Ball Bearing |
| Noise Rating |
37.8dBA |
| Rated Speed |
2000rpm |
| Current Rating |
150mA |
| Air Flow - m3/min |
1.975m³/min |
| Product Range |
CFM-120B Series |
| Fan Frame Type |
Square |
| External Depth |
25.4mm |
| Air Flow - CFM |
69.74CFM |
| Power Rating |
1.8W |
| Power Connection Type |
2 Lead Wires, PWM Control, Tachometer |
| IP Rating |
- |
| Static Pressure |
0.1Inch-H2O |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
SAME SKY |
| Part Number |
CFM-A225B-120-350 |
| Quantity |
Each |
| Technical Data Sheet (71.00B) EN |
View or download |
