Product Overview
SAME SKY CFM-6025BF-290-479-20 DC Axial Fan, 24 V, Square, 60 mm, 25 mm, Ball Bearing, 43.1 CFM
Product details
| Supply Voltage VDC |
24V |
| Fan Frame Size |
60mm |
| Bearing Type |
Ball Bearing |
| Noise Rating |
47.9dBA |
| Rated Speed |
9000rpm |
| Current Rating |
420mA |
| Air Flow - m3/min |
1.22m³/min |
| Product Range |
CFM-60BF Series |
| Fan Frame Type |
Square |
| External Depth |
25mm |
| Air Flow - CFM |
43.1CFM |
| Power Rating |
10.08W |
| Power Connection Type |
2 Lead Wires, Tachometer |
| IP Rating |
- |
| Static Pressure |
0.72Inch-H2O |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
SAME SKY |
| Part Number |
CFM-6025BF-290-479-20 |
| Quantity |
Each |
| Technical Data Sheet (71.00B) EN |
View or download |
