Product Overview
SAME SKY CFM-4020V-050-165 DC Axial Fan, 5 V, Square, 40 mm, 20 mm, omniCOOL, 6.3 CFM
Product details
| Supply Voltage VDC |
5V |
| Fan Frame Size |
40mm |
| Bearing Type |
omniCOOL |
| Noise Rating |
16.5dBA |
| Rated Speed |
5000rpm |
| Current Rating |
87mA |
| Air Flow - m3/min |
0.178m³/min |
| Product Range |
CFM-40V Series |
| Fan Frame Type |
Square |
| External Depth |
20mm |
| Air Flow - CFM |
6.3CFM |
| Power Rating |
440mW |
| Power Connection Type |
2 Lead Wires, Tachometer |
| IP Rating |
- |
| Static Pressure |
0.11Inch-H2O |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
SAME SKY |
| Part Number |
CFM-4020V-050-165 |
| Quantity |
Each |
| Technical Data Sheet (70.00B) EN |
View or download |
