Product Overview
GEMS SENSORS 212460E Turbine Flow Sensor, Liquid, 0.1 to 2.5 LPM, G1/4 Threaded, ± 3%, NPN Open Collector
Product details
| Sensor Type |
Turbine Flow Sensor |
| Flow Rate Max |
2.5l/min |
| Operating Pressure Max |
24bar |
| Supply Voltage Max |
24VDC |
| Sensor Output Type |
NPN Open Collector |
| Process Connection Size |
G1/4 |
| Pipe Size |
- |
| Operating Temperature Min |
-20°C |
| Product Range |
TurboFlow FT-210 Series |
| Flow Rate Min |
0.1l/min |
| Operating Pressure Min |
- |
| Supply Voltage Min |
5VDC |
| Accuracy |
± 3% |
| Media Type |
Liquid |
| Process Connection Type |
BSPP |
| Sensor Mounting |
- |
| Operating Temperature Max |
100°C |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
GEMS SENSORS |
| Part Number |
212460E |
| Quantity |
Each |
| Technical Data Sheet (148.70KB) EN |
View or download |
