Product Overview
AL6M-M14-R is an A6 series LED illuminated pushbutton miniature switch.
- 16mm (5/8”) mounting hole
- Compact design saves space
- Gold-clad silver contact for reliable low-level switching
- Dustproof (IP40) degree of protection
- SPDT contact, momentary switch operation
- Round 18mm lens style, red lens/LED colour
- 24V AC/DC voltage, 3A thermal current
- Operating temperature range from -25º to +55ºC (no freezing)
- Contact resistance is 50mohm maximum (initial value)
- Insulation resistance is 100Mohm minimum (500V DC megger)
Product details
| Product Range |
A6 Series |
| Contact Configuration |
SPDT |
| Pushbutton Actuator Style |
Round |
| Contact Current AC Max |
1A |
| Contact Current DC Max |
1A |
| IP Rating |
- |
| Switch Terminals |
Quick Connect, Solder |
| Panel Cutout (H x W) |
- |
| Panel Cutout Diameter |
16mm |
| Switch Operation |
Momentary |
| Actuator / Cap Colour |
Red |
| Contact Voltage VAC |
110V |
| Contact Voltage VDC |
24V |
| Switch Mounting |
Panel Mount |
| Illumination Colour |
Red |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
IDEC |
| Part Number |
AL6M-M14-R |
| Quantity |
Each |
| Technical Data Sheet (724.95KB) EN |
View or download |
