Product Overview
NICHICON UHE1H221MPD Electrolytic Capacitor, 220 µF, 50 V, ± 20%, Radial Leaded, 1000 hours @ 85°C, Polar
Product details
| Capacitance |
220µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
1000 hours @ 85°C |
| Capacitor Case / Package |
Can |
| Product Diameter |
10mm |
| Product Width |
- |
| Product Range |
UHE Series |
| Ripple Current |
1.05A |
| Operating Temperature Max |
105°C |
| SVHC |
No SVHC (25-Jun-2025) |
| Voltage(DC) |
50V |
| Capacitor Terminals |
Radial Leaded |
| Polarity |
Polar |
| Lead Spacing |
5mm |
| Product Length |
- |
| Product Height |
16mm |
| ESR |
0.34ohm |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
Other details
| Brand |
NICHICON |
| Part Number |
UHE1H221MPD |
| Quantity |
Each |
