Product Overview
00711200 is a Verdin AM62 Solo 512MB V1.2A System on Module (SoM). This is a compact and robust System on Module (SoM) based on the Texas Instruments AM623 SoC, targets a wide range of applications, including industrial automation, medical, transportation, smart cities, test and measurement and many more.
- CPU: 1× Arm Cortex-A53 (up to 1GHz), 1× Cortex-M4F (400MHz)
- Memory: 512MB LPDDR4 RAM (with inline ECC), 4GB eMMC flash (2D MLC), 2kbit (256 × 8bits) I2C EEPROM
- Low speed interfaces: includes 104 GPIOs, 4× I2C, 3× CAN FD, 6× PWM, 5× SPI, 9× UART
- Analog and audio interfaces: 4× analogue input, 2x McASP (I2S or TDM) digital audio
- Camera and display interfaces: 1× Quad-Lane MIPI CSI-2 camera, 1× LVDS (up to 1920×1080)
- Interfaces: SDIO/SD/MMC storage, 1x USB 2.0 host and 1x USB 2.0 OTG
- Networking: Ethernet (GBE with TSN + 2nd RGMII)
- Power supply: 3.135V to 5.5V, 1.8V I/O
- Temperature range from 0°C to +70°C
- Module dimensions is 69.6 x 35.0 x 6.0mm
Product details
| Processor Core Type |
ARM Cortex A53 Single Core, ARM Cortex M4F Single Core |
| Silicon Family Name |
Verdin AM62 |
| RAM Memory Size |
512MB |
| Interfaces |
CAN FD, Ethernet, I2C, MIPI CSI, QSPI/OSPI, SPI, UART, USB |
| Operating Temperature Range |
0°C to 70°C |
| SVHC |
No SVHC (25-Jun-2025) |
| Core Number |
AM6231xKGGHHALW |
| Processor Speed |
1GHz |
| Kit Contents |
Computer-On-Module AM6231xKGGHHALW |
| Operating System |
Torizon Embedded Linux, FreeRtos, Zephyr RTOS |
| Fanless |
- |
Other details
| Brand |
TORADEX |
| Part Number |
00711200 |
| Quantity |
Each |
| Technical Data Sheet (57.00B) EN |
View or download |
