DELTA ELECTRONICS DRL-48V120W1ENA AC/DC DIN Rail Power Supply (PSU), 21.6V to 26.4V, ITE & Laboratory, 1 Output, 120 W, 48 V, 2.5 A

DRL-48V120W1ENA is a delta’s LYTE II DIN rail power supply with slim designed for cost sensitive users who need to fulfil essential features needed for many general industrial applications, without compromising on quality and reliability. The convection-cooled LYTE II will operate full power from -30°C to +50°C, then de-rating up to +70°C at 230V AC. It can operate in constant current mode, making it suitable for inductive and capacitive loads. The product is certified according to safety standards IEC/EN/UL 62368-1. Electromagnetic radiated and conducted emissions are compliant to heavy industrial EN 61000-6-4 class B emission standard and EN 61000-6-2 immunity standard. The product complies with environmental protection requirements as per RoHS directive. It includes overvoltage, overload, overcurrent, over temperature, short circuit protection. Application includes building, machine, process, factory automations.

• Input voltage from 90 to 264V AC, typical efficiency at 100% load is 89.5% at 230V AC
• Rated output voltage is 48V DC, rated output current is 2.5A, rated output power is 120W (max)
• Single phase, no DC OK relay contact, with coating
• Universal AC input voltage range
• Built-in constant current circuit for reactive loads, high power density
• Compliance to SEMI F47 at 200V AC
• Reduced no-load power consumption, compliance with DOE VI energy standard
• Standard TS35 DIN Rail in accordance with EN 60715 mounting
• Operating temperature range from -30°C to +70°C (-40°C cold start)
• Dimension (H x W x D) is 4.87 x 1.18 x 4.60inch (123.69mm x 29.97mm x 116.84mm)
