Product Overview
NXP MCXE31BMPB ARM MCU, MCX Family MCX E31 Series Microcontrollers, ARM Cortex-M7F, 32 bit, 160 MHz, 4 MB
Product details
| Product Range |
MCX Family MCX E31 Series Microcontrollers |
| Data Bus Width |
32 bit |
| Program Memory Size |
4MB |
| IC Case / Package |
HDQFP |
| Interfaces |
CAN, I2C, LPSPI, LPUART, QuadSPI |
| ADC Channels |
24Channels |
| Supply Voltage Min |
2.97V |
| Operating Temperature Min |
-40°C |
| IC Mounting |
Surface Mount |
| MCU Series |
MCX E31 |
| SVHC |
No SVHC (25-Jun-2025) |
| Device Core |
ARM Cortex-M7F |
| Operating Frequency Max |
160MHz |
| No. of Pins |
172Pins |
| No. of I/O's |
- |
| RAM Memory Size |
512KB |
| ADC Resolution |
12Bit |
| Supply Voltage Max |
5.5V |
| Operating Temperature Max |
135°C |
| MCU Family |
MCX |
| Qualification |
- |
