Product Overview
NICHICON UVY1C102MPD ALUMINUM ELECTROLYTIC CAPACITOR 1000UF, 16V, 20%, RADIAL
Product details
| Capacitance |
1000µF |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
1000 hours @ 105°C |
| Capacitor Case / Package |
Radial Leaded |
| Product Diameter |
10mm |
| Product Width |
- |
| Product Range |
UVY Series |
| Ripple Current |
500mA |
| Operating Temperature Max |
105°C |
| SVHC |
6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol (27-Jun-2024) |
| Voltage(DC) |
16V |
| Capacitor Terminals |
PC Pin |
| Polarity |
Polar |
| Lead Spacing |
5mm |
| Product Length |
- |
| Product Height |
12.5mm |
| ESR |
- |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
Other details
| Brand |
NICHICON |
| Part Number |
UVY1C102MPD |
| Quantity |
Each |
