Product Overview
The PFT6 fro TUK is a Cat6 field termination plug is the ideal low-cost solution for timesaving and efficient on-site RJ45 assembly for voice, Cat5e and Cat6 Ethernet cabling. It can be assembled on all standard types of cable, quickly and with no requirement of special tools. Designed for MPTL terminations, this field termination plug offers flexibility and saves time and money on installation, repairs and maintenance.
- Category 6 Class EA Field Termination Plug with 568A and B wiring guide
- High performance – also performs to Category 6A UTP standard
- No tools required for time saving and efficient termination on site
- Suitable for use with stranded or solid core cable – designed for Modular Plug Terminated Link (MPTL) terminations
- Suitable for cable OD 6mm to 8.5mm with core OD 1.0 to 1.5mm, copper core sizes 22AWG to 24 AWG / 0.5mm to 0.65mm
- Rated for 750 mechanical cycles
- NOT suitable for short patch leads
Product details
| Modular Connector Type |
RJ45 Plug |
| No. of Positions / Loaded Contacts (per Port) |
8P8C |
| IP Rating |
- |
| Connector Orientation |
Straight |
| Magnetics |
Without Magnetics |
| Light Pipes |
Without Light Pipe |
| SVHC |
No SVHC (25-Jun-2025) |
| Port Configuration |
1 x 1 (Port) |
| LAN Category |
Cat6 |
| Connector Mounting |
Cable Mount |
| Shielding |
Unshielded |
| LEDs |
Without LED |
| Product Range |
- |
Other details
| Brand |
TUK |
| Part Number |
PFT6 |
| Quantity |
Each |
| Technical Data Sheet (98.00B) EN |
View or download |
