Product Overview
MPBXT-05S09NP is a single-output, 1W, isolated DC to DC converter.
- No-load input current as low as 5mA
- Continuous short-circuit protection
- Unregulated output types
- Operating temperature: -40°C to +105°C
- Industry standard pinout, 14PIN SMD package
- UL/cUL/IEC/EN 62368-1 approved, CB-report
- 9V DC output voltage
- 112mA output current
- 85% typical efficiency
- 5V DC input voltage
Product details
| Power Supply Applications |
ITE & Industrial |
| Input Ratio |
- |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
112mA |
| Output Current - Output 2 |
- |
| Isolation Voltage |
1.5kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
6.25mm |
| Input Voltage DC Min |
4.5V |
| Product Range |
MPBXT-NP |
| DC / DC Converter Type |
Surface Mount DIP |
| Output Power Max |
1W |
| Output Voltage - Output 1 |
9V |
| Output Voltage - Output 2 |
- |
| Output Regulation |
Unregulated |
| Input Voltage DC Nom |
5V |
| Width |
7.6mm |
| Depth |
12.7mm |
| Input Voltage DC Max |
5.5V |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MPBXT-05S09NP |
| Quantity |
Each |
| Technical Data Sheet (804.40KB) EN |
View or download |
| Technical Data Sheet (714.57KB) EN |
View or download |
