Product Overview
MPE-05D24NPH3 is a 1W, isolated DC to DC converter.
- No-load input current as low as 5mA
- Continuous short-circuit protection
- Unregulated output types
- 7PIN SIP package, industry standard pinout
- Operating temperature: -40°C to +105°C
- UL/cUL/IEC/EN 62368-1 approved, CB-report
- 5V DC input voltage
- Output voltage: ±24V DC
- Output current: ±21mA
- 85% typical efficiency
Product details
| Power Supply Applications |
ITE & Industrial |
| Input Ratio |
- |
| No. of Outputs |
2 Output |
| Output Current - Output 1 |
21mA |
| Output Current - Output 2 |
-21mA |
| Isolation Voltage |
3kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
10mm |
| Input Voltage DC Min |
4.5V |
| Product Range |
MPE-NPH3 |
| DC / DC Converter Type |
SIP |
| Output Power Max |
1W |
| Output Voltage - Output 1 |
24V |
| Output Voltage - Output 2 |
-24V |
| Output Regulation |
Unregulated |
| Input Voltage DC Nom |
5V |
| Width |
6mm |
| Depth |
19.5mm |
| Input Voltage DC Max |
5.5V |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MPE-05D24NPH3 |
| Quantity |
Each |
| Technical Data Sheet (475.34KB) EN |
View or download |
