Product Overview
MPA-05D05NP is a 1W, dual-output isolated DC to DC converter.
- 7PIN SIP package, industry standard pinout
- No-load input current as low as 5mA
- Continuous short-circuit protection
- Unregulated output types
- Operating temperature:-40°C to +105°C
- UL/cUL/IEC/EN 62368-1 approved
- Output voltage: ±5V DC
- Output current: ±100mA
- Efficiency: 82% typical
- 5V DC input voltage
Product details
| Power Supply Applications |
ITE & Industrial |
| Input Ratio |
- |
| No. of Outputs |
2 Output |
| Output Current - Output 1 |
100mA |
| Output Current - Output 2 |
-100mA |
| Isolation Voltage |
1.5kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
10mm |
| Input Voltage DC Min |
4.5V |
| Product Range |
MPA-NP |
| DC / DC Converter Type |
SIP |
| Output Power Max |
1W |
| Output Voltage - Output 1 |
5V |
| Output Voltage - Output 2 |
-5V |
| Output Regulation |
Unregulated |
| Input Voltage DC Nom |
5V |
| Width |
6mm |
| Depth |
19.5mm |
| Input Voltage DC Max |
5.5V |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MPA-05D05NP |
| Quantity |
Each |
| Technical Data Sheet (427.95KB) EN |
View or download |
