Product Overview
The HFD27/024-S is a subminiature DIP signal relay designed for PCB mounting. It features a 24V DC coil and a 2 Form C (DPDT) contact configuration, providing flexible switching options in compact electronic circuits. This relay is capable of switching up to 2A at 30VDC or 1A at 125VAC, with a maximum switched voltage of 120V DC or 240V AC. It uses bifurcated contacts for reliable low-level signal switching and is epoxy sealed, making it suitable for automatic wave soldering and cleaning processes. The HFD27/024-S is commonly used in telecommunications, instrumentation, and other applications where compact size, high reliability, and signal integrity are essential.
- 2 Form C Configuration
- Matching 16 pin IC socket
- Bifurcated contacts
- Epoxy sealed for automatic-wave soldering and cleaning
Product details
| Coil Voltage |
24VDC |
| Contact Current |
2A |
| Relay Mounting |
Through Hole |
| Relay Terminals |
PC Pin |
| Contact Voltage VDC |
120V |
| Coil Resistance |
2.88kohm |
| Contact Configuration |
DPDT |
| Product Range |
HFD27 Series |
| Coil Type |
Non Latching |
| Contact Voltage VAC |
240V |
| Contact Material |
Silver Nickel |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
HONGFA |
| Part Number |
HFD27/024-S |
| Quantity |
Each |
