Product Overview
The HF118F/012-1ZS1T(136) is a miniature high-power PCB relay manufactured by Hongfa, designed for reliable switching in compact electronic and industrial control systems. It features a 12V DC coil and a single pole changeover contact configuration (SPDT, 1 Form C), capable of handling switching currents up to 10A at 250VAC or 30VDC.
- Coil Voltage: 12V DC
- Contact Arrangement: SPDT (1 Form C)
- Contact Rating: 10 A at 250 VAC / 30V DC
- Terminal Type: Solder
- Ambient Temperature Range: -40°C to +85°C
- Dielectric Strength: 5kV (between coil and contacts)
Product details
| Contact Configuration |
SPDT |
| Contact Current |
10A |
| Relay Mounting |
Through Hole |
| Contact Voltage VAC |
250V |
| Contact Voltage VDC |
30V |
| Coil Resistance |
620ohm |
| Coil Voltage |
12VDC |
| Product Range |
HF118F Series |
| Coil Type |
Non Latching |
| Relay Terminals |
PC Pin |
| Contact Material |
Silver Tin Oxide |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
HONGFA |
| Part Number |
HF118F/012-1ZS1T(136) |
| Quantity |
Each |
