Product Overview
The HF115F/024-2ZS4AF is a miniature high power relay designed for 24V DC coil operation. It belongs to the HF115F series, which is widely used in consumer electronics, industrial control systems, and household appliances due to its compact size and high switching capacity. Featuring a 24V DC and a DPDT (2 Form C) contact configuration, this relay offers excellent electrical endurance and insulation performance.
- Coil Voltage: 24V DC
- Contact Arrangement: DPDT (2 Form C)
- Contact Rating: 8 A at 250 VAC (resistive load)
- Terminal Type: Solder
- Ambient Temperature Range: -40°C to +85°C
- Dielectric Strength: 5kV (between coil and contacts)
Product details
| Contact Configuration |
DPDT |
| Contact Current |
8A |
| Relay Mounting |
Through Hole |
| Contact Voltage VAC |
250V |
| Contact Voltage VDC |
- |
| Coil Resistance |
1.44kohm |
| Coil Voltage |
24VDC |
| Product Range |
HF115F Series |
| Coil Type |
Non Latching |
| Relay Terminals |
PC Pin |
| Contact Material |
Silver Tin Oxide |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
HONGFA |
| Part Number |
HF115F/024-2ZS4AF |
| Quantity |
Each |
