Product Overview
The HF115F/024-1ZS3AF is a miniature high power relay designed for 24V DC coil operation. It is part of the HF115F series, which is widely used in household appliances, industrial automation, and control systems due to its compact form factor and high switching capacity. Featuring a 24V DC and a SPDT (1 Form C) contact configuration, this relay offers excellent electrical endurance and insulation performance.
- Coil Voltage: 24V DC
- Contact Arrangement: SPDT (1 Form C)
- Contact Rating: 16 A at 250 VAC (resistive load)
- Mounting: PCB terminals
- Terminal Type: Solder
- Dielectric Strength: 5,000 VAC (coil to contacts)
- Ambient Temperature Range: -40°C to +85°C
Product details
| Contact Configuration |
SPDT |
| Contact Current |
16A |
| Relay Mounting |
Through Hole |
| Contact Voltage VAC |
250V |
| Contact Voltage VDC |
- |
| Coil Resistance |
1.44kohm |
| Coil Voltage |
24VDC |
| Product Range |
HF115F Series |
| Coil Type |
Non Latching |
| Relay Terminals |
PC Pin |
| Contact Material |
Silver Tin Oxide |
| SVHC |
No SVHC (25-Jun-2025) |
Other details
| Brand |
HONGFA |
| Part Number |
HF115F/024-1ZS3AF |
| Quantity |
Each |
