NXP S32E288AACAAMJGT Microprocessor, 32 bit, S32E2 Family, 10 Cores, 800 MHz, MAPBGA-975, -40 to 125 °C
Product details
| Product Range |
S32E2 Family S32E288 Series Microprocessors |
| Program Memory Size |
32MB |
| No. of Pins |
975Pins |
| Supply Voltage Max |
5V |
| Interfaces |
CAN, Ethernet, FlexRay, I2C, I3C, LIN, SENT, SPI, USART, Zipwire |
| Data Bus Width |
32 bit |
| Operating Temperature Min |
-40°C |
| Qualification |
AEC-Q100 |
| MPU Family |
S32E2 |
| No. of CPU Cores |
10Cores |
| IC Case / Package |
MAPBGA |
| Supply Voltage Min |
800mV |
| Operating Frequency Max |
800MHz |
| No. of I/O's |
- |
| IC Mounting |
Surface Mount |
| Operating Temperature Max |
125°C |
| MPU Series |
S32E288 |
| SVHC |
No SVHC (21-Jan-2025) |
