Product Overview
TE CONNECTIVITY L000486-05 Internal Antenna, Flexible, Linear, 3.8GHz to 4.2GHz, 5G/Cat-M/Cellular/FPC/LTE/NB-IoT
Product details
| Antenna Band |
Wide Band |
| Frequency Range |
698MHz to 960MHz, 1.427GHz to 1.517GHz, 1.69GHz to 2.2GHz, 3.3GHz to 3.8GHz, 3.8GHz to 4.2GHz |
| Gain |
1.3dBi, 3.8dBi, 3.2dBi, 3.5dBi, 3.9dBi |
| Product Range |
- |
| Operating Temperature Min |
-40°C |
| Antenna Polarisation |
Linear |
| Antenna Type |
Flexible |
| VSWR |
3:1, 2.5:1 |
| Antenna Mounting |
Adhesive |
| Protocol |
5G / Cat-M / Cellular / FPC / LTE / NB-IoT |
| Operating Temperature Max |
85°C |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
TE CONNECTIVITY |
| Part Number |
L000486-05 |
| Quantity |
Each |
| Technical Data Sheet (2.60MB) EN |
View or download |
