Product Overview
MCXE246VLL is a MCX E24 series industrial and IoT (IIoT) microcontroller (MCU) that delivers reliable performance for harsh environments, featuring scalable connectivity options, advanced safety features and robust 5V architecture. Designed to ensure high reliability and safety, the 5V robust MCU series thrives in harsh electrical noise environments, making it ideal for safe appliances and industrial applications. The MCX E24 Series expands on the Kinetis E family, featuring the familiar Arm® Cortex®-M4F core supporting 3V to 5V power supply and enhanced memory configurations. These improvements ensure powerful, flexible performance across a variety of use cases. Additionally, the MCX E24 Series offers multiple connectivity options for local networks, including CAN FD, 10/100Mbps Ethernet audio and low power serial communication, enabling seamless integration into diverse systems.
- 112MHz cortex-M33 MCU
- 1024KB flash, 128KB SRAM
- 3x CAN (with 2 FD)
- Available in 100 pin LQFP package
Product details
| Product Range |
Kinetis E Family MCX E24 Series Microcontrollers |
| Data Bus Width |
32 bit |
| Program Memory Size |
1MB |
| IC Case / Package |
LQFP |
| Interfaces |
CAN, LPI2C, LPSPI, LPUART |
| ADC Channels |
2Channels |
| Supply Voltage Min |
2.7V |
| Operating Temperature Min |
-40°C |
| IC Mounting |
Surface Mount |
| MCU Series |
MCX E24 |
| SVHC |
No SVHC (21-Jan-2025) |
| Device Core |
ARM Cortex-M4F |
| Operating Frequency Max |
112MHz |
| No. of Pins |
100Pins |
| No. of I/O's |
84I/O's |
| RAM Memory Size |
128KB |
| ADC Resolution |
12Bit |
| Supply Voltage Max |
5.5V |
| Operating Temperature Max |
125°C |
| MCU Family |
Kinetis E |
| Qualification |
- |
Other details
| Brand |
NXP |
| Part Number |
MCXE246VLL |
| Quantity |
Each |
| Technical Data Sheet (2.11MB) EN |
View or download |
