Description
Product Overview
ADZS-180PWM-SAM is a PWM 180-pin probing board (extender board). This extender board plugs onto the ADSP-CM403F and ADSP-CM408F EZ-KIT Lite® evaluation systems. The extender board aids the design and prototyping phases of processor-targeted applications. The board extends the capabilities of the evaluation system by providing a point for probing any signal of the 180-pin asynchronous bus and PWM expansion interface connectors.
- Board features two 180-pin connectors (Samter QSH-090-01-F-D-A and Samter QTH-090-01-F-D-A)
- Five probing headers (Samter TSW-118-07-L-D)
- Ten GND headers (FCI 90726-402HLF)
Contents
PWM 180-pin probing board, Hardware for securing the extender board onto the EK-KIT Lite.
Product details
| Silicon Manufacturer | Analog Devices |
| Core Sub-Architecture | Cortex-M4 |
| Silicon Family Name | ADSP-CM40x |
| Kit Contents | PWM 180-Pin Probing Board, Hardware |
| SVHC | No SVHC (04-Feb-2026) |
| Core Architecture | ARM |
| Silicon Core Number | ADSP-CM403F, ADSP-CM408F |
| For Use With | ADZS-CM403F EZ & ADZS-CM408F EZ Boards |
| Product Range | - |
Other details
| Brand | ANALOG DEVICES |
| Part Number | ADZS-180PWM-SAM |
| Quantity | Each |
| Technical Data Sheet (523.59KB) EN | View or download |
