Product Overview
INTELLIGENT LED SOLUTIONS ILH-ON01-YELL-SC211-WIR200. LED Module, 80° Angle, OSLON SSL 80 1 PowerStar Series, Yellow, 590 nm, 2.6 V, Star
Product details
| Product Range |
OSLON SSL 80 1 PowerStar Series |
| Wavelength Typ |
590nm |
| Supply Voltage |
2.6V |
| Operating Temperature Min |
-40°C |
| Luminous Flux @ Max |
- |
| Forward Current @ Test |
350mA |
| SVHC |
No SVHC (04-Feb-2026) |
| LED Colour |
Yellow |
| Luminous Flux @ Test |
- |
| Power Module Configuration |
Star |
| Operating Temperature Max |
110°C |
| Power Rating |
810mW |
| LED Module Type |
Board + LED + Connecting Wire |
Other details
| Brand |
INTELLIGENT LED SOLUTIONS |
| Part Number |
ILH-ON01-YELL-SC211-WIR200. |
| Quantity |
Each |
| Technical Data Sheet (74.00B) EN |
View or download |
