Product Overview
SANYO DENKI 9HV1248P1H001 DC Axial Fan, 48 V, Square, 120 mm, 38 mm, Ball Bearing, 254 CFM
Product details
| Supply Voltage VDC |
48V |
| Fan Frame Size |
120mm |
| Bearing Type |
Ball Bearing |
| Noise Rating |
72dBA |
| Rated Speed |
10000rpm |
| Current Rating |
1.4A |
| Air Flow - m3/min |
7.2m³/min |
| Product Range |
San Ace 120 9HV Series |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
254CFM |
| Power Rating |
67W |
| Power Connection Type |
3 Lead Wires, Pulse Sensor, PWM Control |
| IP Rating |
- |
| Static Pressure |
1050Pa |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
SANYO DENKI |
| Part Number |
9HV1248P1H001 |
| Quantity |
Each |
