Product Overview
SANYO DENKI 9GL1224H101 DC Axial Fan, 24 V, Square, 120 mm, 38 mm, Ball Bearing, 99 CFM
Product details
| Supply Voltage VDC |
24V |
| Fan Frame Size |
120mm |
| Bearing Type |
Ball Bearing |
| Noise Rating |
39dBA |
| Rated Speed |
2600rpm |
| Current Rating |
220mA |
| Air Flow - m3/min |
2.8m³/min |
| Product Range |
San Ace 120L 9GL Series |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
99CFM |
| Power Rating |
5.28W |
| Power Connection Type |
3 Lead Wires, Pulse Sensor |
| IP Rating |
- |
| Static Pressure |
70.4Pa |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
SANYO DENKI |
| Part Number |
9GL1224H101 |
| Quantity |
Each |
| Manufacturer Catalogue (3.59MB) EN |
View or download |
