Product Overview
SANYO DENKI 9AD0901H1H AC Axial Fan, 100V to 240V, Square, 92 mm, 38 mm, 53 CFM
Product details
| Nominal Rated Voltage AC |
100V to 240V |
| Fan Frame Size |
92mm |
| Bearing Type |
- |
| Noise Rating |
40dBA |
| Rated Speed |
3850rpm |
| Current Rating |
80mA |
| Air Flow - m3/min |
1.5m³/min |
| Operating Voltage Max |
264V |
| Product Range |
San Ace 92AD Series |
| Fan Frame Type |
Square |
| External Depth |
38mm |
| Air Flow - CFM |
53CFM |
| Power Rating |
4.5W |
| Power Connection Type |
Lead Wires, Sensor Output with Connector |
| IP Rating |
- |
| Operating Voltage Min |
90V |
| Static Pressure |
90Pa |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
SANYO DENKI |
| Part Number |
9AD0901H1H |
| Quantity |
Each |
| Technical Data Sheet (1.11MB) EN |
View or download |
