Product Overview
Also known as
44PUGR5680T89K
Product details
| Dielectric Type |
Metallized PP |
| Capacitance |
68µF |
| Typical Applications |
AC Filter |
| Voltage(AC) |
780V |
| Humidity Rating |
GRADE III (Test Condition B) |
| Lead Spacing |
35mm |
| Peak Current |
- |
| ESR |
1500µohm |
| Product Length |
- |
| Product Height |
247mm |
| Output (kvar) |
- |
| Operating Temperature Min |
-30°C |
| Qualification |
- |
| Capacitor Case / Package |
Can |
| Capacitance Tolerance |
± 10% |
| Capacitor Mounting |
Stud Mount - M12 |
| Voltage(DC) |
1.7kV |
| Capacitor Terminals |
Screw |
| dv/dt Rating |
70V/µs |
| RMS Current (Irms) |
55A |
| Product Diameter |
85mm |
| Product Width |
- |
| Ripple Current |
55A |
| Product Range |
C44P-T Series |
| Operating Temperature Max |
70°C |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
KEMET |
| Part Number |
C44PUGR5680T89K |
| Quantity |
Each |
