Product Overview
HZ102F ultra-thin prismatic cell is ideal for use in space-constrained devices. It is a single cell capacitor for ultra-thin designs & primary batteries/harvesters.
- Operate at 2.75V/cell (2.9V peak)
- 170mF capacitance with ±20% tolerance
- 90mohm ESR
- 20.0 x 15.0 size
- Temperature range from -40°C to +70°C
- UL-810 and ISO 9001:2015 certified
- Very low leakage current (<1µA)
Product details
| Capacitance |
0.17F |
| Capacitor Terminals |
Solder |
| Lead Spacing |
- |
| Capacitor Case / Package |
SMD |
| ESR |
0.09ohm |
| Product Length |
20mm |
| Product Height |
1.2mm |
| Operating Temperature Min |
-40°C |
| Qualification |
- |
| Voltage(DC) |
2.75V |
| Capacitance Tolerance |
± 20% |
| Lifetime @ Temperature |
- |
| Capacitor Mounting |
Surface Mount |
| Product Diameter |
- |
| Product Width |
15mm |
| Product Range |
HZ102 Series |
| Operating Temperature Max |
70°C |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
CAP-XX |
| Part Number |
HZ102F |
| Quantity |
Each |
| Technical Data Sheet (85.00B) EN |
View or download |
