Product Overview
GUS350-36/ADJ is a GUS350 series single output, general purpose AC-DC power supply. It is designed to provide reliable performance at an economical price. Typical applications include industrial, test, LED, broadcast, COMM, and Semi-Fab.
- Complies with SEMI F47
- Compact size, saves space in system
- Conservative electrolytic capacitor ratings, long field life
- Class B conducted and radiated EMI, easier system EMC compliance
- IEC62368-1 certification, compliant to IEC61010-1, quicker system compliance
- 35.1 - 38.8V output adjustment
- 9.8A maximum current
- 352.8W maximum output power
- 480mV ripple and noise
- Size (WxHxD):101.6 x 41 x 127mm, 3 years warranty
Product details
| Power Supply Applications |
ITE, Industrial & Laboratory Equipment |
| Output Power Max |
352.8W |
| Output Current - Output 1 |
9.8A |
| Output Current - Output 2 |
- |
| Output Current - Output 3 |
- |
| Output Current - Output 4 |
- |
| Power Supply Output Type |
Adjustable |
| SVHC |
No SVHC (21-Jan-2025) |
| No. of Outputs |
1Outputs |
| Output Voltage - Output 1 |
38.8V |
| Output Voltage - Output 2 |
- |
| Output Voltage - Output 3 |
- |
| Output Voltage - Output 4 |
- |
| Input Voltage VAC |
85V AC to 265V AC |
| Product Range |
GUS350-1000 Series |
Other details
| Brand |
TDK-LAMBDA |
| Part Number |
GUS350-36/ADJ |
| Quantity |
Each |
| Technical Data Sheet (108.00B) EN |
View or download |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
