Product Overview
77.E2.9.024.8671 is a 77 series Hockey puck solid state relay. It is ideal for heater or motor control.
- 75/750A rated current IN/max. peak current (10ms), 600V AC (50/60Hz) rated voltage
- 2 independent output channel driven by independent low power DC input
- “Hockey puck” housing with folding screw cover
- High endurance and switching speed, silent switching, spark and bounce-free switching
- Contactor-style: input and output terminals on adjacent sides
- Mounting on control cabinet sheet metal or on heatsink
- 2NO output configuration
- Operating frequency range from 47 to 400Hz
- Ambient temperature range from -30 to +80°C
Product details
| Contact Configuration |
DPST-NO |
| Operating Voltage Max |
660VAC |
| Relay Terminals |
Screw |
| Operating Voltage Min |
24VAC |
| Control Voltage Max |
32VDC |
| SVHC |
No SVHC (04-Feb-2026) |
| Load Current |
75A |
| Relay Mounting |
Panel Mount |
| Switching Mode |
Random Turn On |
| Control Voltage Min |
4VDC |
| Product Range |
77 Series |
Other details
| Brand |
FINDER |
| Part Number |
77.E2.9.024.8671 |
| Quantity |
Each |
| Technical Data Sheet (47.00B) EN |
View or download |
