Product Overview
VTX-MIC12 is a microphone input transformer with through-hole PCB pins. Transformer is designed to interface microphones with the input stage of audio equipment, such as mixing consoles, preamplifiers, or recording devices.
- 1 C.T. : 2+2 turns ratio
- Max input: +9dBu at 20Hz with <1% THD
- 150 ohm input impedance
- Frequency range from 15Hz to 60kHz
- Fitted with multiple electrostatic screens
- Low distortion Mu-metal core
- Mu-metal screening can reduces electrical noise by up to 30dB
- Operating temperature range from 0 to +70°C
Product details
| Turns Ratio |
1CT:2, 1CT:4 |
| Secondary Impedance |
0 |
| Frequency Max |
- |
| Transformer Applications |
Microphone Input Transformer |
| DC Resistance Secondary |
500ohm |
| Transformer Terminals |
PC Pin |
| Product Range |
VTX Series |
| Primary Impedance |
150ohm |
| Secondary Power |
- |
| Isolation Voltage |
500VDC |
| DC Resistance Primary |
20ohm |
| Transformer Mounting |
Through Hole |
| Frequency Min |
- |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
VIGORTRONIX |
| Part Number |
VTX-MIC12 |
| Quantity |
Each |
| Technical Data Sheet (51.00B) EN |
View or download |
