Product Overview
MDS01M-05N is a MDS01-N (New) series 1W isolated and unregulated module type medical grade DC-DC converter with SIP7 package with internal standard pinout. Suitable for medical devices, medical oxygen monitor, CT scanning, medical carts, oral care equipment, telecom/ datacom system, wireless network, industrial control facility.
- Input voltage range from 10.8V DC to 13.2V DC
- Single output of 5V DC
- Comply with IEC/UL2368-1 and LVD IEC60601-1
- Medical safety approved (1xMOPP/2xMOOP) according to IEC60601-1
- Low patient leakage current <2µA
- Protection: short circuit(continuous)
- 6KV DC high I/O isolation (reinforced insulation)
- Low cost
- 3 years warranty
- Operating temperature range from -40 to 95°C
Product details
| Power Supply Applications |
ITE, Industrial & Medical |
| Input Ratio |
- |
| No. of Outputs |
1 Output |
| Output Current - Output 1 |
200mA |
| Output Current - Output 2 |
- |
| Isolation Voltage |
6kV |
| DC / DC Converter Output Type |
Fixed |
| Height |
11.5mm |
| Input Voltage DC Min |
10.8V |
| Product Range |
MDS01-N Series |
| DC / DC Converter Type |
SIP |
| Output Power Max |
1W |
| Output Voltage - Output 1 |
5V |
| Output Voltage - Output 2 |
- |
| Output Regulation |
Unregulated |
| Input Voltage DC Nom |
12V |
| Width |
7.1mm |
| Depth |
19.7mm |
| Input Voltage DC Max |
13.2V |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
MEAN WELL |
| Part Number |
MDS01M-05N |
| Quantity |
Each |
| Technical Data Sheet (222.39KB) EN |
View or download |
