Product Overview
MULTICOMP PRO MCPDMT50J050JB00 Resistor, 5 ohm, MP PDMT Series, 50 W, ± 5%, Solder Lug, 1.25 kV
Product details
| Resistance |
5ohm |
| Power Rating |
50W |
| Resistor Terminals |
Solder Lug |
| Resistor Technology |
Wirewound |
| Resistor Type |
High Power |
| Product Length |
50.5mm |
| Product Height |
15.7mm |
| Operating Temperature Max |
275°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Product Range |
MP PDMT Series |
| Resistance Tolerance |
± 5% |
| Voltage Rating |
1.25kV |
| Temperature Coefficient |
± 100ppm/°C |
| Resistor Mounting |
Chassis Mount |
| Product Width |
30mm |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MCPDMT50J050JB00 |
| Quantity |
Each |
| Technical Data Sheet (340.80KB) EN |
View or download |
