Product Overview
MULTICOMP PRO MCPDMT25J0153B00 Resistor, 15 kohm, MP PDMT Series, 25 W, ± 5%, Solder Lug, 550 V
Product details
| Resistance |
15kohm |
| Power Rating |
25W |
| Resistor Terminals |
Solder Lug |
| Resistor Technology |
Wirewound |
| Resistor Type |
High Power |
| Product Length |
28mm |
| Product Height |
14mm |
| Operating Temperature Max |
275°C |
| SVHC |
No SVHC (04-Feb-2026) |
| Product Range |
MP PDMT Series |
| Resistance Tolerance |
± 5% |
| Voltage Rating |
550V |
| Temperature Coefficient |
± 180ppm/°C |
| Resistor Mounting |
Chassis Mount |
| Product Width |
27mm |
| Operating Temperature Min |
-55°C |
| Qualification |
- |
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MCPDMT25J0153B00 |
| Quantity |
Each |
| Technical Data Sheet (353.45KB) EN |
View or download |
