Product Overview
Also known as
N1hKSW3 30;24V;1.25A;;Clamps;S;
Product details
| Power Supply Applications |
ITE, Household, Medical, LED Lighting |
| Output Power Max |
30W |
| Output Current - Output 1 |
1.25A |
| Output Current - Output 2 |
- |
| Output Current - Output 3 |
- |
| Input Voltage VAC |
90V AC to 264V AC |
| Height |
33.65mm |
| Product Range |
N1hxyW3 30 Series |
| No. of Outputs |
1 Output |
| Output Voltage - Output 1 |
24V |
| Output Voltage - Output 2 |
- |
| Output Voltage - Output 3 |
- |
| Power Supply Output Type |
Fixed |
| Width |
53.1mm |
| Depth |
57.1mm |
| SVHC |
No SVHC (04-Feb-2026) |
Other details
| Brand |
PULSE ELECTRONICS |
| Part Number |
003920666 |
| Quantity |
Each |
| Technical Data Sheet (2.19MB) EN |
View or download |
