Product Overview
KUNBUS PR100413 RevPi Connect 5 Base Module, 4GB, 10.8 to 28.8V in, 4 Core, ARM Cortex-A76, RPi OS, RS485/WLAN+BT
Product details
| Processor Type |
ARM Cortex-A76 |
| RAM Memory Size |
4GB |
| Operating System Support |
Raspberry Pi OS |
| Supply Voltage Max |
28.8VDC |
| Operating Temperature Min |
-25°C |
| IP Rating |
IP20 |
| EMI, Surge / Burst Tests |
- |
| No. of Cores |
4 Cores |
| eMMC Flash Memory |
32GB |
| Supply Voltage Min |
10.8VDC |
| Power Consumption |
22W |
| Operating Temperature Max |
60°C |
| ESD Protection |
- |
| SVHC |
No SVHC (21-Jan-2025) |
Other details
| Brand |
KUNBUS |
| Part Number |
PR100413 |
| Quantity |
Each |
| Technical Data Sheet (623.90KB) EN |
View or download |
